Bộ ghi dữ liệu nhiệt độ Hioki- Nhật Bản, LR 5011 (-40.0°C tới 180°C) xuất xứ nhật bản, 1 kênh đo, thiết kế nhỏ gọn, đo dùng cảm biến ngoài
Thông số kỹ thuật:
Hãng sản xuất: Hioki- Nhật Bản
Xuất xứ: Nhật Bản
Bảo hành: 12 Tháng
Chức năng: Đo nhiệt độ với sensor ngoài
Kênh đo: 1 kênh đo nhiệt độ
Dải đo: -40.0°C tới 180°C (phụ thuộc vào sensor)
Độ chính xác: ±0.5°C( 0°C tới 35°C )
Tiểu chuẩn chống bụi và chống nước: IP54
Môi trường làm việc của thiết bị: -20°C(-4°F) tới 70°C(158°F) , 80%rh hay nhỏ hơn
Kích thước & trọng lượng: Khoảng 79mm W×57mm H×28mmD, 105g
Nguồn cấp: LR6 (AA) Alkaline battery 1.5V×1
Phụ kiện: Alkaline battery 1.5V×1, sách hướng dẫn sử dụng
TEMPERATURE LOGGER LR5011
Key Features
• Easily mount the light-weight , pocket-sized loggers in tight spaces • Easy-to-see dual display • Transfer data to PC even during recording • Replace batteries while recording (30 second limit) • 3 times the memory capacity than predecessor (Record 60,000 data per channel) • Record without missing fluctuations in STAT mode • Measurement data is preserved even after the battery dies • Worry-free backup preserves recorded data even if a new measurement is started by mistake
Specifications:
| Measurement items | Temperature 1ch (with optional sensor) |
| Measurement range | -40.0 °C to 180.0 °C *Depends on measurement range of sensor |
| Basic accuracy | ±0.5 °C (main unit + sensor accuracy, at 0.0 to 35.0 °C) Note: Basic accuracy is typical value, refer to the detailed catalog |
| Storage capacity | Instantaneous value mode: 60,000 data, Statistical value mode: 15,000 data |
| Recording interval | 1 to 30 sec., 1 to 60 min., 15 selections |
| Recording modes | Instantaneous recording: at every recording interval Statistical value recording: Measure at one second intervals, and record the instantaneous, maximum, minimum, and average values within every recording interval |
| Recording methods | One-time recording: Stop recording when the memory capacity is full Endless recording: Continue recording even when the memory capacity is full (old data is overwritten) Start: Logger button operation or scheduled time Stop: Logger button operation or scheduled time, or auto-stop when the memory capacity is full (at one-time recording) |
| Other functions | Always backs up last recorded data; backs up recorded data and setting conditions when battery power is low; guarantees approx. 30 sec. of recording operation and clock while battery is replaced |
| Waterproof and dust-proof | IP54 (EN60529) (with sensor connected, but not including sensor tip) |
| Interfaces | Infrared optical communications with LR5091, LR5092-20 |
| Power supply | LR6 (AA) Alkaline battery × 1, Battery life: Approx. 2 years (Instantaneous recording, with 1-minute interval and auto power saving, at 20 °C), Approx. 2 months (Instantaneous recording, with 1-second interval at 20 °C) |
| Dimensions and mass | 79 mm (3.11 in) W × 57 mm (2.246 in) H × 28 mm (1.10 in) D, 105 g (3.7 oz) |
| Accessories | LR6 (AA) Alkaline battery (built-in internal) × 1, Instruction manual × 1, Operation guide × 1, Kickstand × 1 |
