Máy hiện sóng sô 2 kênh Peaktech- Đức, 1240 (60 MHz/2 CH, 500 MSa/s, 2 CH)
Thông số kỹ thuật:
Hãng sản xuất: Peaktech- Đức
Xuất xứ: China
Bảo hành: 12 Tháng
|
Băng thông |
60 MHz |
|
Màn hình hiên thị |
20 cm (8”) TFT with 65536 colors |
|
Đô phân giải |
800 x 600 Pixel |
|
Số kênh |
2 CH |
|
Chế độ lấy mẫu |
normal/peak detect/average |
|
Tốc độ lấy mẫu mỗi kênh |
250 MSa/s |
|
Đầu vào Coupling |
AC, DC, GND |
|
Trở kháng đầu vào |
1 MΩ +/- 2 % in parallel with 10 pF +/- 5 pF |
|
Điện áp đầu vào |
400 V DC or ACpp |
|
Độ nhạy |
2 mV – 10 V/Skt/div. |
|
Rise time |
< 5,8 ns |
|
Cấp chính xác |
+/- 3 % |
|
Vertical resolutions |
8 Bits (2 CH simultaneously) |
|
Horizontal scale |
5ns-100s/Skt./div |
|
Sampling range |
0,5 – 250 S/s |
|
Trigger type |
Edge/Video/Pulse/Slope |
|
Chế độ Trigger |
Auto, Normal, Single |
|
Trigger coupling |
DC, AC, LF, HF |
|
Đo tự động |
peak-peak, cycle RMS, Vmax, Vmin, Vtop, Vbase, Vamp, overshoot, preshoot, rise time, fall time, +width, -width, +duty, -duty, delay A→B (rising), delay A→B(falling), frequency, period, min, max |
|
Độ lệch pha |
+/- 3° |
|
Record length |
10.000.000 points/CH |
|
Giao diện |
USB Device 2.0, USB Host 2.0, VGA, LAN |
|
Điện áp hoạt động |
100 ~ 240 V ACrms / 50/60 Hz |
|
Kích thước (WxHxD) |
340 x 155 x 70 mm |
|
Trọng lượng |
1,8 kg |
|
Phụ kiện đi kèm |
BNC cable, USB cable, software CD for Windows 2000/XP/VISTA/7, power cable, 2 probes, carrying case and manual |
60 MHz/2 CH, 500 MSa/s, Digital Storage Oscilloscope
Digital storage osczilloscope of the latest generation with high-resolution color display, backlight, high bandwith and high sampling rate, VGA-output, large internal memory, USB port and LAN connection for integration into networks. The amazing value for money and modern technology allows a wide range of applications in education, service and quality assurance area.
- High-resolution TFT color display with 800 x 600 pixels and 65536 colors
- USB port for real-time data transmission or reading of internal memory
- Saving of measured values and graphics directly onto the USB-stick
- VGA-output port for external monitor
- Autoset and autoscale function for easy operation
- LAN connection for remote acces via network
- Internal memory of 10 million points per channel or 15 waveforms
- 20 automatic measurement modes and FFT function
- PASS/FAIL function
- Safety: EN 61010-1; CAT II
- Accessories: 2 pcs. BNC cable, USB cable, software CD for Windows 2000/XP/VISTA/7, power cable, 2 probes, carrying case and manual
- Optional accessories: accu pack 7,4 V, model: AKKU 3
|
Bandwidth |
60 MHz |
|
Display |
20 cm (8”) TFT with 65536 colors |
|
Resolution |
800 x 600 Pixel |
|
Channel |
2 CH |
|
Sampling mode |
normal/peak detect/average |
|
Sampling rate each Channel |
250 MSa/s |
|
Input coupling |
AC, DC, GND |
|
Input impedance |
1 MΩ +/- 2 % in parallel with 10 pF +/- 5 pF |
|
Input voltage |
400 V DC or ACpp |
|
Sensitivity |
2 mV – 10 V/Skt/div. |
|
Rise time |
< 5,8 ns |
|
Accuracy |
+/- 3 % |
|
Vertical resolutions |
8 Bits (2 CH simultaneously) |
|
Horizontal scale |
5ns-100s/Skt./div |
|
Sampling range |
0,5 – 250 S/s |
|
Trigger type |
Edge/Video/Pulse/Slope |
|
Trigger mode |
Auto, Normal, Single |
|
Trigger coupling |
DC, AC, LF, HF |
|
20 automat. measurements |
peak-peak, cycle RMS, Vmax, Vmin, Vtop, Vbase, Vamp, overshoot, preshoot, rise time, fall time, +width, -width, +duty, -duty, delay A→B (rising), delay A→B(falling), frequency, period, min, max |
|
Phase difference |
+/- 3° |
|
Record length |
10.000.000 points/CH |
|
Interfaces |
USB Device 2.0, USB Host 2.0, VGA, LAN |
|
Operation voltage |
100 ~ 240 V ACrms / 50/60 Hz |
|
Dimensions (WxHxD) |
340 x 155 x 70 mm |
|
Weight |
1,8 kg |
