Máy hiện sóng số và phân tích logic Peaktech- Đức, 1190 (100 MHz/2CH, 100MHz/16 CH)
Thông số kỹ thuật:
Hãng sản xuất: Peaktech- Đức
Xuất xứ: Peaktech- Đức
Bảo hành: 12 Tháng
CHỨC NĂNG MÁY HIỆN SÓNG :
Băng thông: 100 MHz
Màn hình hiển thị: 20 cm 8” TFT (640 x 480 Pixel)
Số kênh: 2 CH + ext. Trigger + Logic-Analyzer
Sample rate: 500 MSa/s (real time) each channel
Sampling mode: normal, peak detection, average
Vertical sensitivity: 2 mV – 10 V/div
Input impedance: 1 MΩ ± 2 % in parallel with 15 pF ± 3 pF
Điện áp vào lớn nhất: 400 V DC or ACpp
Input coupling: DC/AC/GND
Cấp chính xác: ± 3 %
Rise time: < 3,5 ns
Resolution A/D: 8 bits (2 CH simultaneously)
Time base: 5 ns – 100 s/div.
Trigger mode: edge, pulse, video, alternate, slope
Autom. measurements: peak-peak, cycle RMS, Vmax, Vmin, Vtop, Vbase, Vamp, overshoot, preshoot, rise time, fall time, +width, -width, +duty, -duty, delay A-B (rising), delay A-B (falling), frequency, period, mean
Math. waveform: Addition, Subtraktion, multiplikation, division, FFT
Record length: max. 2 Mio. Punkte (1 CH)
Waveform storage: 4 waveforms
CHỨC NĂNG PHÂN TÍCH LOGIC :
Băng thông: 100 MHz
Số kênh: 16
Sample rate: 20Sa/s ~ 1 GSa/s
Input impedance: 660 kΩ ± 5 %; 15 ± 5 pF
Input singal range: -6 V ~ +6 V
Threshold voltage: -30 V ~ +30 V
Trigger mode: egde, bus, sequential queue data, distributed queue data and data width trigger
Position setting: pre, mid, post
Record length: 4 Mio. points per channel, 16 k at 500 MSa/s
Data system: binary-, decimal system, hex
Digital-Filter: 0, 1, 2 opt.
THÔNG SỐ CHUNG :
Giao diện: USB Device 2.0, USB Host 1.1
Điện áp: 100 ~ 240 V ACrms / 50 Hz
Dimensions (WxHxD): 370 x 180 x 120 mm
Weight : 2,2 kg
EAN-13: 4250569400162
100 MHz/2 CH, Digital Storage Oscillosope with 100 MHz/16 CH logic analyzer
100 MHz Digital storage oscilloscope of the latest generation with 16 CH logic analyzer and 20 cm (8”)- TFT- color display, high resolution, backlight and USB function benefits faster and larger data communication. The current electronic products become more complicated as the number of digital circuits and serial bus systems increase; the testing signal often mixes analog and digital signals so the engineer needs an test instrument that could test both of analog and digital signals. Provides versatile applications for educations, training centers, repair and maintenance and satisfies increasing needs of higher performance.
- Save data directly to an USB-stick
- 100 MHz bandwidth
- 500 MSa/s sampling rate per each channel
- 16 logic input channels
- Max. 2 Mio. points record length for each channel
- Dual channels + external trigger + logic analyzer
- Support USB 2.0 data transmission, display by real-time
- Advanced trigger functions: edge, bus, pattern, sequential queue data, distributed queue data and data width trigger
- Autoscale-function, supports automatic setting of waveform- and data detecting
- Safety: EN 61010-1 : 2001; CAT II
- Accessories: carrying case, 2 pcs. BNC cable, USB cable, software CD for Windows 2000/XP/VISTA/7/8/10, power cable, logic probe, 2 pcs. oscilloscope probes and manual
|
OSCILLOSCOPE : |
|
|
Bandwidth |
100 MHz |
|
Display |
20 cm 8” TFT (640 x 480 Pixel) |
|
Channel |
2 CH + ext. Trigger + Logic-Analyzer |
|
Sample rate |
500 MSa/s (real time) each channel |
|
Sampling mode |
normal, peak detection, average |
|
Vertical sensitivity |
2 mV – 10 V/div |
|
Input impedance |
1 MΩ ± 2 % in parallel with 15 pF ± 3 pF |
|
Max input voltage |
400 V DC or ACpp |
|
Input coupling |
DC/AC/GND |
|
Accuracy |
± 3 % |
|
Rise time |
< 3,5 ns |
|
Resolution A/D |
8 bits (2 CH simultaneously) |
|
Time base |
5 ns – 100 s/div. |
|
Trigger mode |
edge, pulse, video, alternate, slope |
|
Autom. measurements |
peak-peak, cycle RMS, Vmax, Vmin, Vtop, Vbase, Vamp, overshoot, preshoot, rise time, fall time, +width, -width, +duty, -duty, delay A-B (rising), delay A-B (falling), frequency, period, mean |
|
Math. waveform |
Addition, Subtraktion, multiplikation, division, FFT |
|
Record length |
max. 2 Mio. Punkte (1 CH) |
|
Waveform storage |
4 waveforms |
|
LOGIC ANALYZER : |
|
|
Bandwidth |
100 MHz |
|
Channels |
16 |
|
Sample rate |
20Sa/s ~ 1 GSa/s |
|
Input impedance |
660 kΩ ± 5 %; 15 ± 5 pF |
|
Input singal range |
-6 V ~ +6 V |
|
Threshold voltage |
-30 V ~ +30 V |
|
Trigger mode |
egde, bus, sequential queue data, distributed queue data and data width trigger |
|
Position setting |
pre, mid, post |
|
Record length |
4 Mio. points per channel, 16 k at 500 MSa/s |
|
Data system |
binary-, decimal system, hex |
|
Digital-Filter |
0, 1, 2 opt. |
|
GENERAL : |
|
|
Interfaces |
USB Device 2.0, USB Host 1.1 |
|
Operation voltage |
100 ~ 240 V ACrms / 50 Hz |
|
Dimensions (WxHxD) |
370 x 180 x 120 mm |
|
Weight |
2,2 kg |
|
EAN-13 |
4250569400162 |
