Testo 316-4 Set 1 – Reference Leak Detector 0563 3164
Technical Data:
Operating temperature: -20 to +50 °C
Operating humidity: 20 to 80 %RH
Storage temperature: -25 to +70 °C
Power supply: 1 battery block (6 cells NiMh)
Battery life: 6 h (Continuous operation)
Dimensions: 190 x 57 x 42 mm
Weight: 348 g
Warranty: 24 months (instrument and sensor)
Start-up time: <50 s (0 to +50 °C)
<80 s (-20 to 0 °C)
Length of gooseneck: 370 mm
Complies with:1g/year sensitivity acc. to EN 14624 and E 35-422
Leakage alarm: optical and audible alarm
Reaction time: <1 s
lower reaction threshold: 3 g/a
Detectable: R134a, R22, R404a, H2 and all common refrigerants
such as CFC, HCFC, HFC NH3 (separate sensor head)
Description
The testo 316-4 (Set 1) is a fast and reliable leakage detector for all common refrigerants. The sensor is permanently monitored and shows malfunctions or contamination in the display. The use of test leaks is thus superfluous.
If dirty, the sensor can simply be cleaned, and is immediately ready for use again. The very high level of sensitivity of ⟨3g/a according to EN 14624 allows the detection of the smallest leakages. The display changes from green to red when leaks occur. An audible signal additionally indicates detected leakages. With the earphone, testo 316 can also be used in loud surroundings. The trend display shows maximum leakages and facilitates the localization of leaks. The flexible gooseneck allows the optimum positioning of the sensor close to the pipe or other measurement site.
|
Storage temperature |
-25 to +70 °C |
|---|---|
|
Operating temperature |
-20 to +50 °C |
|
Battery life |
6 h |
|
Weight |
348 g |
|
Dimensions |
190 x 57 x 42 mm |
