Thiết bị đo khí CO, O2, CO2 và nhiệt độ TPI- MỸ, TPI 709

Carbon Monoxide (CO)
 Measurement

 Range 0 to 10,000 ppm
 Resolution 1 ppm
 Accuracy +/-5ppm or 5% of reading whichever is greater

 Oxygen (02) Measurement

 Range 0 to 25%
 Resolution 0.1%
 Accuracy ±0.3%

 Carbon Dioxide (CO2)

 Range 0 to 25%
 Resolution 0.1%
 Calculated Value

 Nitric Oxide Measurement

 N/A

 NOX Measurement

 N/A

 Temperature Measurement

 Range -40 to 1472°F, or -40 to 800°C
 Resolution 1°F or °C
 Accuracy (K-type) ±0.3%, ±2°F or ±1°C

 Draft/Pressure
 Measurement

 Selectable Ranges mBar,kPa, and inH2O
 Ranges -150 mBar to +150 mBar -15 kPa to +15 kPa -60
 inH2O to +60 in H20
 Resolution 0.001 inH2O
 Accuracy ±0/5% fsd

 Gross/Net Efficiency

 Range 0 to 100%
 Resolution 0.1%
 Calculated Value

 CO/CO2 Ratio

 Range 0 to 0.999
 Resolution 0.001
 Calculated Value

 Operating Temperature

 14°F to 122°F (-10°C to 50°C)

 Battery Type

 1.5V AA (3)

 Selectable Fuels

 Natural Gas, LPG, Light Oil, Heavy Oil, Bituminous Coal,
 Anthracite Coal, Coke, Butane, Wood, Bagasse

 Display Type

 Backlit 3 line LCD

 Data Storage

 50 Locations

 Data Logging

 N/A

 Print Capability

 Yes, via optional IR printer (A740)

 PC Communication

 N/A

 Date and Time Function

 24 Hour Real Time Clock

 Dimensions

 200mm x 90mm x 60mm

 Weight

 500g

 Conformity

 BS7927 (and the draft BS7967)
