Thiết bị đo nhiệt độ, độ ẩm PCE- Anh, PCE-313A( Có thẻ nhớ)

Name: Thiết bị đo nhiệt độ, độ ẩm PCE- Anh, PCE-313A( Có thẻ nhớ) - BAC Việt Nam
SKU: 1379
Price: 8850000 VND
Availability: InStock

8.850.000 ₫

Mã sản phẩm: 1379

Liên hệ trực tiếp

CHI TIẾT
THÔNG SỐ KĨ THUẬT

Thông số kỹ thuật:

Hãng sản xuất: PCE- Anh

Bảo hành: 12 Tháng

Khoảng đo

– Độ ẩm tương đối   5 ~ 95 % R.H.

– Nhiệt độ   0 ~ +50 °C

– Sensor Kiểu K   -50 ~ +1300 ºC

– Tính toán điểm sương   -25,3 ~ +48,9 ºC

– Nhiệt độ kết ẩm( độ nồm) -21 ~ +50 ºC

Độ phân giải

– Độ ẩm tương đối   0,1 % R.H.

– Nhiệt độ   0,1 °C

– Sensor Kiểu K   0,1 °C

– Tính toán điểm sương   0,1 °C

– Nhiệt độ kết ẩm   0,1 °C

Độ chính xác

– Nhiệt độ ±0,8 ºC

– Độ ẩm tương đối ≥70 % H.r.±3 % giá trị đo + 1 % H.r.

– Kiểu K ± (0,4 % + 0,5 ºC)

Bộ nhớ Thẻ SD (card) (1~ 16 GB)

Tốc độ đo Có thể điều chỉnh, 1 ~ 3600 giây

Màn hình LCD 52 x 38 mm có đèn nền

Kết nối máy tính RS-232

Điều kiện hoạt động 0 … +50 °C < 85 % H.r.

Nguồn 6 pin x 1,5 V / Adaptor 9 V (tùy chọn)

Kích thước máy 177 x 68 x 45 mm

Khối lượng Khoảng 490 g

Cung cấp bao gồm

Máy PCE-313A, sensor đo nhiệt độ, độ ẩm, 1 x SD card (2 GB), đầu đọc thẻ, 6 pin và hướng dẫn sử dụng.

Phụ kiện (tùy chọn)

– Bộ chuẩn độ ẩm 33%, 75%

– Phần mềm và cáp USB

– Bộ đổi nguồn AC sang DC

PCE-313A hydrometer with SD memory card tester of humidity to measure relative humidity and temperature, with internal memory through the SD card (1 to 16 GB) / interface for real time data transference / powered by battery or mains component / additional connection for thermo-elements
The PCE-313A hydrometer is designed for professional use in the air-conditioning sector. The PCE-313A hydrometer determines both relative humidity and ambient temperature. The PCE-313A hydrometer can be connected to type K thermo-elements to detect, for instance, the temperature of a wall by means of a surface probe. The internal memory of the PCE-313A hydrometer allows humidity and temperature values to be recorded with a free adjustment of the measurement rate for real time measurements or data storage thanks to its SD memory card (1 to 16 GB). The PCE-313A hydrometer can be programmed via the keypad in advance so the device can record values without the user being present during the process. For long term records we recommend you to power the PCE-313A hydrometer by means of mains (optional). Recorded values can be transferred to a PC for further analysis (xls file in the SD card). This feature allows you to check measured values or design a graphic using Excel program. At the following link you can find another hygrometer to measure relative humidity, temperature and dew point. Here is an overview of all the hygrometers you might need.
View or print user manual PCE-313 A
For high humidity environment the new PCE-313S hydrometer with a sintered hood placed on both the temperature and the humidity sensor is available. Due to its design sensor it can be used in adverse conditions without any delay in the measurement. The sintered hood of the PCE-313S hydrometer can be removed to be cleaned, calibrated or tested. The image on the right shows the sensor with the sintered hood for the PCE-313S hydrometer.
	There is an optional piece of calibration equipment available for the PCE-313 A hydrometer. Humidity sensors become less accurate over time which is also true for this model. To ensure that values are always accurate, the hydrometer can be recalibrated using the calibration standards. These humidity standards have a value of 33% and 75% of relative humidity. This calibration can be done by people with limited experience using a hydrometer.
Characteristics
– Measures temperature, humidity, dew point and temperature via the connection to a thermo- element – Memory with possibility of real time registration by means of the SD memory card (1 to 16 GB) – Data is directly stored in Excel format in the SD card – The SD card can be formatted in the hydrometer – Data-Hold Function – External sensor for an easy and flexible measurement of the environmental conditions – Low battery indication – Large LCD display – Connection for tripod – Measurement rate adjustment from 1 to 3600 seconds – Easy-to-use – Solid case – 2 GB SD card and card reader included in the delivery – Optional software for real time data transference to a computer or portable computer (no additional software is required for data analysis)


Technical specifications:
Ranges – Relative humidity – Temperature – Type K – Calculated dew point – Wet bulb temperature	5 … 95 % H.r. 0 … +50 °C -50 … +1300 ºC -25.3 … +48.9 ºC -21 … +50 ºC
Resolution – Relative humidity – Temperature – Type K – Calculated dew point – Wet bulb temperature	0.1 % H.r. 0.1 °C 0.1 °C 0.1 °C 0.1 °C
Accuracy – Temperature – Relative humidity – Type K	± 0.8 ºC ≥70 % H.r. ± 3 % of the measurement value, + 1 % H.r. &LT70 % H.r. ±3 % H.r. ± (0.4 % + 0.5 ºC)
Memory	SD card (1 … 16 GB)
Measurement rate	adjustable, 1 … 3600 seconds
Display	LCD of 52 x 38 mm, with backlight
Interface	RS-232
Operating conditions	0 … +50 °C < 85 % H.r.
Power supply	6 x 1.5 V batteries/9 V mains adapter (optional)
Dimensions	177 x 68 x 45 mm
Weight	approx. 490 g
Delivery content: 1 x PCE-313A or PCE-313S hydrometer (with sintered hood), 1 x combined sensor for temperature and humidity, 1 x SD card (2 GB), 1 x card reader, 6 x batteries, 1 x carrying bag and user manual.
Optional accessories
– ISO Calibration Certificate For companies that wish to incorporate the device into their internal quality control devices or for annual recalibrations (if not using the calibration kit). The ISO certificate includes a calibration and a document containing all the readings. The first calibration is done when the device is ordered. Annual recalibration can be also performed.
– Humidity calibration kit For the PCE-320 calibration. The kit is composed of two humidity standards (33 and75% r.h.). Simply place the sensor in the standards and press a button.
– Software kit with USB cable The software is required in order to transmit data from the internal memory of the device to a computer. They can then be exported to other calculation programs such as MS Excel. USB cable is included.
– Mains component Mains component to use the device via the mains (230 V/50 Hz). Ideal for long-term registrations.
