Detector of refrigerant gases and hydrogen DF110

Specifications:

Manufacturer: KIMO- France

Origin: France

Warranty: 12 Months

Detected gases

            HFC : R134a, R404a, R407c, R410a, R32, R422a/b/c/d,

            R425a, R507a, R125

            HCFC : R22

            CFC : R12 et R502

            Others : H2, R290, R600a, HFO-1234yf

Measuring element: Semi-conductor sensor

Display 13 leds :

– 8 for the graphic visualization of thresholds

– 3 for the sensitivity of detection

– 2 for the battery level and manual autozero

Indication:

            LED : gradual lighting up when the gas concentration increases

            Audible : the beep frequency increases when the gas concentration increases

Probe: Flexible, 400 mm length

Autonomy:  > 12 hours

Housing:  Anti-choc ABS, protection IP54

Keypad: 3 keys

Conformity: EMC 2004/108/CE and EN 61010-1 Directives

Power supply: 4 AAA LR03 1.5 V batteries

Ambiance: Neutral gas

Operating temperature: From 0 to +50 °C

Storage temperature: From -20 to +80 °C

Auto-extinction: 15 min

Weight: 295 g
